| System | |
|---|---|
| Main Processor | ARM Cortex A7 Processor |
| Operating System | Embedded LINUX |
| Video | |
| Input | 9CH (8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/D1/CIF) |
| Output | 1× HD |
| Audio | |
| Audio Bit Rate | 64 kbps |
| Compression | G711U, G711A, MP2L2 |
| Alarm & Detection | |
| Motion Detection | 9CH, 396 zones (22×18) |
| Trigger Events | Recording, Email, FTP, Snapshot, Pop-up, Notify Center |
| Display | |
| HD Output | 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| Display Split | 9CH / 8CH / 6CH / 4CH / 2CH / 1CH |
| Digital Zoom | Yes |
| Recording | |
| Compression | H.265 / H.264 / H.265+ / H.264+ |
| Max Resolution | 4K (3840×2160) |
| Record Mode | Manual / Timer / Motion / Smart Event |
| Network | |
| Interface | RJ45 10/100 Mbps |
| Bandwidth | 72 Mbps Incoming / 48 Mbps Outgoing |
| ONVIF | Profile S & T |
| Mobile Access | iPhone & Android |
| Storage | |
| Interface | 1 SATA (3.5″) |
| Capacity | Up to 8TB |
| General | |
| Power | DC48V / ≤6W |
| Working Temp | -10°C ~ 50°C |
| Dimensions | 200 × 175 × 40 mm |
| Weight | 1.5 kg |
Note : Product performance is based on testing in a controlled environment. Your results may vary due to several external and environmental factors.
